Hydraulic jaw crusher 300×1300 mm
PEY300×1300 hydraulic jaw crusher is designed for coarse and medium crushing under heavy conditions of material mixed with very hard and very strong foreign substances, especially for processing steel slag, the machine is equipped with a special hydraulic station. When the crusher encounters indestructible material, it can free itself from it using the hydraulic unloading device and buffer device without damaging the machine itself. Hydraulic jaw crusher is a type of jaw crusher with overload protection function by hydraulic support device. The loading material size is no more than 250mm, has the advantages of simple structure, reliable operation, convenient operation, safe use and so on.
Hydraulic jaw crusher is widely used in metallurgy, mining, building materials, chemical industry, coal and other industries, mainly used in primary crushing of products. With its own constant vibration, it can crush large stones into small pieces, which is suitable for crushing rock after blasting to make it easier to transport and use. In addition, the hydraulic jaw crusher also has an overload protection function. When the tiger bites the non-crushing material, the protection device will automatically relieve the load to avoid the body being affected by sudden increased load, so as to improve safety during the crushing process.
Description |
Parameter |
|
Inlet size（mm） |
300×1300 |
|
Outlet adjustment range（mm） |
20～90 |
|
Maximum inlet size（mm） |
250 |
|
Eccentric shaft rotation（r/min） |
300 |
|
Capacity（m³/h） |
10～65 |
|
Engine |
Type |
Y315S—6 |
Power（KW） |
75 |
|
revolution（r/min） |
990 |
|
Size(L*W*H)（mm） |
2631×2320×1766 |
|
Equipment weight (without engine)（Kg） |
13300 |
|
